Cast Resin Technology

A long term protection in terms of insulation values and resistance for all kinds of cable accessories & cross-sections is guaranteed by high grade two components PUR cast resins and shock proof plastic moulds. After hardening, the cable joints are resistant to mechanical & electrical loads.


Features :

  • Easy mixing; no need of spatula, etc.
  • Easy assembly.
  • High quality transparent Polycarbonate plastic shell.
  • Good adhesion of Resin to PVC ensures watertight seal.
  • Hydrophobic & corrosion resistance.
  • Superior electrical, mechanical & chemical properties.
  • Shelf life of Cast Resin= 48 months at ambient temperature{15°C to 35°C}.

  • Product Range :

  • LV cast resin straight through joint.
  • LV cast resin branch joint.
  • Cast Resins & Hardener.


  • Selection Table :

    Cable Size mm2
    Cast Resin Joints
    1.5-10
    ASCR-31
    16-25
    ASCR-32
    35-50
    ASCR-33
    70-95
    ASCR-34
    120-150
    ASCR-35
    185-300
    ASCR-36

    Note:
    Ascon has high profile In-house testing in accreditation to the ISO 9001 quality assured standards.
    Type Test Reports are available on request.


    * We reserve the right to make any technical changes or modify in content..
